Product Overview
The LW8-40.5 is an outdoor high-voltage circuit breaker that uses sulfur hexafluoride (SF6) gas for both insulation and arc extinguishing. Rated at 40.5kV with a choice of 1600A or 2000A rated current, its medium-mounted outdoor configuration is designed for substations and distribution networks. A spring operating mechanism provides high-speed switching, and the breaker integrates circuit-breaker failure protection and overcurrent protection functions for system security.
Key Features
- SF6 gas insulation and arc extinguishing: Sulfur hexafluoride gas serves as both the insulating medium and the arc-extinguishing medium, enabling a compact outdoor design with reliable dielectric performance at 40.5kV.
- 40.5kV rated voltage: Engineered for high-voltage distribution networks, with a 95kV power frequency withstand voltage supporting insulation requirements in outdoor substations.
- 1600A / 2000A rated current options: Two rated current options cover different feeder load levels, allowing selection to match the continuous load current of the installation.
- Spring operating mechanism: The spring-charged mechanism delivers consistent high-speed contact operation, with tripping energy stored mechanically rather than depending on auxiliary power at the moment of fault clearing.
- Circuit-breaker failure and overcurrent protection: Integrated protection functions guard against breaker malfunction and overload conditions, improving overall system security.
- 3-pole outdoor configuration: Three-pole design for three-phase switching in medium-mounted outdoor installations, rated for 3000 mechanical operations.
- ISO9001-2000 certified with OEM/ODM support: Manufactured under ISO9001-2000 quality management with a 12-month warranty, MOQ of 1 piece, and customization available from the factory in Zhejiang, China.
Product Attributes
| Customization | Available |
| Breaking Capacity | High Voltage Circuit Breakers |
| Operation | Spring Operating Mechanism |
| Model NO. | LW8-40.5 |
| Speed | High-Speed Circuit Breaker |
| Arc-extinguishing Medium | SF6 |
| Installaton | Outdoor Installation |
| Poles Number | 3 |
| Type | Circuit Breaker |
| Function | Circuit-Breaker Failure Protection, Overcurrent Protection |
| Certification | ISO9001-2000 |
| Product Name | Hv Sulfur Hexafluoride Circuit Breakers |
| Service | OEM/ODM |
| MOQ | 1PCS |
| Warranty | 12 Months |
| Customize | Yes |
| Rated Voltage | 40.5kv |
| Lightning Impulse Withstand Voltage | 40.5kv |
| Power Frequency Withstand Voltage | 95kv |
| Rated Current | 1600/2000A |
| Mechanical Lifespan | 3000time |
| Rated Gas Pressure of Sulfur Hexafluorid | 0.5MPa |
| Alarm Pressure | 0.47MPa |
| Minimum Functional Pressure | 0.15MPa |
| Transport Package | Wood Box |
| Specification | Custom |
| Trademark | HaiRui |
| Origin | Zhejiang,China |
| Package Size | 1.00cm*1.00cm*1.00cm |
| Package Gross Weight | 1.000kg |
Applications
Suitable for 40.5kV outdoor substations, distribution substations, and industrial power systems requiring SF6 gas insulated switching. The medium-mounted configuration suits installations where the breaker is mounted on a support structure in outdoor switchyards. Buyers should confirm the required rated current (1600A or 2000A), system voltage, and protection scheme compatibility before ordering.
